    One Side Aluminum Foil Fiberglass Fabric 0.6mm For Heat Reflective

    0.55mm AL-FW600 With One Side Aluminum Foil Coated Fiberglass Fabric Used For Heat Reflective


    1. Description:


    The heat-reflective aluminum foil glass fiber cloth is made of aluminum foil and Fiberglass cloth. This kind of cloth reflects more than 95% of radiant heat. This cloth can also be used with a self-adhesive backing. This adhesive is acrylic resin (Water Base Glue)and Pressure Sensitive Oil Adhesive and will burn or evaporate when the temperature exceeds 400 degrees Fahrenheit. This kind of cloth is commonly used to make covers for insulating equipment, welding curtains and blankets.


    Product Construction
    Materlal CompositionMaterial DescriptionValue Standard
    FoilAluminum

    9&18 Micron


    AdhesivePressure Sensitive Oily Adhesive and Water Base Glue

    Adjust according to different thickness of base fabric


    Fiberglass ClothEach difference Thickness Cloth

    75-2000g




    2. Table 2: Data Sheet of AluminumFiberglass Cloth


    AL-FW600
    Item ModelAluminum Foil Fiberglass FabricTest Standard
    Weave StructureEven grain check
    Thread CountWarp15 per cm38 per inchGB/T 7689.2-2013
    Weft15 per cm38 per inch
    Final Product Weight600 g/ m217.6 OZ/YD2ASTM D3776-96
    Thickness0.55 mm0.022 inchASTM D1777-96
    CoatingAluminum foil/Metalized film + PET
    Coating Thickness9micron/18micron0.28/0.7/0.98mil
    ColorSilver
    Break StrengthWarp6000 N/5cm666 lbs/inchGB/T 7689.5-2013
    Weft5000 N/5cm555 lbs/inch
    Width100cm40 inch
    120cm48 inch
    150cm60 inch
    SERVICE TEMPERATUREFiberglass is 550℃, while mucilage is 300℃
    Flame ResistanceNon-Combustible Cloth
    AdvantagesRadiant Thermal Reflective


    3. What is the Aluminum Foil Fiberglass Cloth Application?


    • Heat insulation material for steam heating pipes
    • Sound insulation material in construction
    • Protective layer
    • Oil pipelines
    • Steam pipelines in the petrochemical industry,​
    • Steel construction
    • Temperature sensitive storage area

    4. Product Features:


    • Reflects 97% of radiant heat
    • Fire Protection
    • Durable and lightweight
    • Easy to cut and install
    • Not affected by moisture or humidity

    5. Detail images for Aluminum Foil Cloth



    6: Other Related Products


    Item no.WeaveDensity per cmWeight g/m2ThicknessAluminum Foil ThicknessTensile Strength
    N/5cm
    Warp & WeftWarp & Weft

    AL75


    Plain12*8750.1mm7Micron380*370

    AL7628


    Plain18*12200g/m20.2mm7Micron2025*1620

    AL3732


    3x1 Twill18*12430g/m20.43mm7/18Micron6000*4500

    ALFW600


    Double Plain15*15600g/m20.55mm7/18Micron6000*5000

    AL2025


    Plain8*5.7610g/m20.75mm7/18Micron2025*1216

    AL-M30


    Plain6*3.81020g/m21.2mm7/18Micron3000*2200

    AL-3784


    Satin18*13880g/m20.9mm7/18Micron8000*6000

    Other thickness and weight can also be customized according to your Requirement


    75g<Weight<2000g


    0.1mm<Thickness<3mm
