    1.5mm Thickness M30 Texturized Fiberglass Cloth Fiberglass Woven Roving Cloth

    Ask Lasest Price
    Brand Name : Shenghe
    Model Number : M30
    Certification : ISO 9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 10000 meters per day
    Delivery Time : 10-15 Work Days
    • Product Details
    • Company Profile

    1.5mm Thickness M30 Texturized Fiberglass Cloth Fiberglass Woven Roving Cloth

    1.5mm Thickness M30 Texturized Fiberglass Cloth Fiberglass Woven Roving Cloth


    Product Description

    Woven roving is a great option for boat building, especially with chopped strand mats. Woven roving is a heavy, coarse plain weave cloth. Bundles of roving are woven together loosely at 90 degrees. It comes in 18 and 24-oz weights. (We only sell the 24 oz woven roving by the yard).

    Woven roving is used to build up thickness quickly. The continuous filaments add strength. A drawback is that with the woven bundles there is crimping. The crimp points can fracture.

    Typically when using woven roving, it is alternately layered with a chopped strand mat. The reason to use a mat with roving is because of the knobbiness (bumpiness) of the roving. It is hard to adhere another layer of roving or cloth to it. There will be many voids left behind if done so. It will also be heavy from the extra resin needed to fill those voids.


    Total weight: 1020g/m2.

    Width: 1m~2m

    Roll Length: 50m~300m

    Packing: carton and pallet

    The following is the specification sheet of texturized fiberglass fabric for reference.


    Technique Data Sheets

    Product NameM30 Texturized Fiberglass Cloth
    Thickness0.8mm
    Width1000mm
    Length50.1m
    Weave StructurePlain
    Weight1020gsm
    Yarn Density Treads/cmWarp Density6
    Weft Density3.8
    Yarn TypeWarpET9-816 T 860
    WeftET9-1224 T 1250
    ColorLight Yellow

    Product Features

    Texturized fiberglass yarns withstand temperatures up to 1000°F

    The product is entirely incombustible.
    Chemical Resistance: Resists most acids, alkalis, and
    solvents except for hydrofluoric acid and hot phosphoric.


    Main applications:

    The fiberglass plain weave fabric is a fabric woven in plain method with E-glass
    or C-glass roving. It is also named "E-glass or C-glass roving cloth.” The fabric
    could be easily impregnated with resin and it comes out with high adhesion strength; additionally, this fabric is with high performance in chemical-corrosion resistance, fire resistance, heat resistance, and durability. So as it is widely used in GFRP (glass fiber reinforced plastics) industry and other chemical-corrosion, fire-resistance, and heat-resistant material and projects.


    Much More Related

    Product CodeWeight ±5%Thickness

    g/m²
    Oz/rd²mmInch
    842152908.50.40.02
    202558017.00.80.13
    262695027.81.00.16
    M2481024.00.80.13
    M30102030.01.20.20
    M70200060.02.00.33

    Much More Deatil Images for 2025


    Jiangnan Glass Fiber Co Quality Control Profile.

    1. Jiangnan has strict and meticulous quality control in all aspects of the production process, to ensure product quality.
    2. Jiangnan brings in professional test equipment, which can test the quality of every finished fiberglass fabric.
    3. ISO9001: 20000 System Certification and other third part certificates authenticated.
